EDP Protection for Busbars systems

EDP Protection for Busbars systems

Training contents:

  • Registration of currents in normal operating mode
  • Registration of currents in the event of single-, double- or triple-pole short circuit
  • Faults outside the protective domain
Basic equipment set, consisting of:
1
Transmission line model 150km/300km (93.2miles/186.4miles)
Transmission line model 150km/300km (93.2miles/186.4miles) CO3301-3A
3
Double busbar unit, three-phase, incoming / outgoing feeder
Double busbar unit, three-phase, incoming / outgoing feeder CO3301-5R
1
Variable Ohmic load, three-phase, 1kW
Variable Ohmic load, three-phase, 1kW CO3301-3F
1
Ohmic load 3x 560 Ohm
Ohmic load 3x 560 Ohm CO3301-3H
1
Set of Balancing transformer
Set of Balancing transformer CO3301-4Y
1
Time Overcurrent Relay
Time Overcurrent Relay CO3301-4J
1
Power switch module
Power switch module CO3301-5P
Media:
1
Interactive Lab Assistant: Protection for bus bar systems
Interactive Lab Assistant: Protection for bus bar systems SO2800-9M
Software:
1
Software SCADA Viewer
Software SCADA Viewer SO4001-3H
Power supply:
1
Adjustable 3-phase power supply, 0-450V/2A
Adjustable 3-phase power supply, 0-450V/2A CO3301-3Z
1
Multiple socket outlet, 6 fold, with illuminated switch
Multiple socket outlet, 6 fold, with illuminated switch ST8010-4J
Measuring instruments:
1
Three-phase power quality meter, display and long-term memory
Three-phase power quality meter, display and long-term memory CO5127-1S
Accessories:
1
Patch cable Cat5E 1x 1 m yellow, 2x 2 m yellow
Patch cable Cat5E 1x 1 m yellow, 2x 2 m yellow LM9057
1
USB 2.0 Ethernet adapter, 10/100
USB 2.0 Ethernet adapter, 10/100 LM8257
1
5-Port Ethernet Switch
5-Port Ethernet Switch LM9988
1
Interface converter USB/RS485
Interface converter USB/RS485 LM9025
50
Safety connecting plug 4mm with tap (2x), black, 1000V/32A CAT II
Safety connecting plug 4mm with tap (2x), black, 1000V/32A CAT II SO5126-3R
2
Safety connecting plug 4mm with tap (2x), blue, 1000V/32A CAT II
Safety connecting plug 4mm with tap (2x), blue, 1000V/32A CAT II SO5126-3V
2
Safety connecting plug 4mm with tap (2x), gr/ye, 1000V/32A CAT II
Safety connecting plug 4mm with tap (2x), gr/ye, 1000V/32A CAT II SO5126-3W
1
Set of safety measurement cables, 4mm, 31 pcs
Set of safety measurement cables, 4mm, 31 pcs SO5148-1L
1
Mobile aluminum experiment stand, 3 levels, power strip with 6 sockets,(1250 x 1970 x 700 mm)
Mobile aluminum experiment stand, 3 levels, power strip with 6 sockets,(1250 x 1970 x 700 mm) ST7200-4C
Additionally recommended:
1
Display for Energy Distribution equipment
Display for Energy Distribution equipment ST8000-4N
1
Monitor holder for flat screen monitor of weight up to 15kg/33lbs
Monitor holder for flat screen monitor of weight up to 15kg/33lbs ST8010-4T
1
Keyboard adapter for flat screen monitor holders
Keyboard adapter for flat screen monitor holders ST8010-4G
1
Protection cover for three-level experiment trolleys
Protection cover for three-level experiment trolleys ST8010-9Y
