Thanks to their clearly arranged control structure, converters with DC motors are particularly well suited for programming your very own initial control algorithms. The training system permits implementation, optimization and operation of your own control configurations. In addition to classic approaches, this open system enables you to also safely explore new ideas and novel expansions.

Training objectives:

  • Setting up a hardware-in-the-loop system under real-time conditions
  • Modelling and designing cascade closed-loop control for a DC motor on an ongoing design level
  • Reducing the control system to discrete components to run on a digital signal processor
  • Creation and optimization of automatic flow-rate and speed controllers
  • Speed detection using incremental sensors
  • Comparison of simulation results with actual measurements
Basic equipment set, consisting of:
1
Self-commutated converter circuits
Self-commutated converter circuits CO3636-3B
1
USB adapter with MATLAB toolbox for power electronics and process control
USB adapter with MATLAB toolbox for power electronics and process control CO3636-3D
1
DC multi-circuit, compound wound machine, 1 kW
DC multi-circuit, compound wound machine, 1 kW SE2682-5D
1
Incremental position encoder 1024 pulses, 1 kW
Incremental position encoder 1024 pulses, 1 kW SE2683-5T
1
Three-phase isolating transformer 1300VA
Three-phase isolating transformer 1300VA CO3636-3G
1
Regulating transformer, exciter 0-200 V
Regulating transformer, exciter 0-200 V CO3212-5Q
1
Field regulator for generators, 1kW
Field regulator for generators, 1kW CO3213-6H
1
Coupling guard 1 kW with LED lighting
Coupling guard 1 kW with LED lighting SE2662-7D
1
Rubber coupling sleeve, 1kW
Rubber coupling sleeve, 1kW SE2662-6A
Media:
1
Interactive Lab Assistant: Inverter-fed drives with DC motors 1 kW
Interactive Lab Assistant: Inverter-fed drives with DC motors 1 kW SO2805-2N
1
Interactive Lab Assistant: DC drives using MATLAB-Simulink 1 kW
Interactive Lab Assistant: DC drives using MATLAB-Simulink 1 kW SO2805-2R
Additionally required, dynamic servo machine test stand:
1
Servo machine test stand for 1kW machines incl. software ActiveServo (D,GB,F,E)
Servo machine test stand for 1kW machines incl. software ActiveServo (D,GB,F,E) CO3636-6Y
1
Rubber coupling sleeve, 1kW
Rubber coupling sleeve, 1kW SE2662-6A
1
Coupling guard 1 kW with LED lighting
Coupling guard 1 kW with LED lighting SE2662-7D
Measuring instruments:
1
Power-Multimeter
Power-Multimeter CO5127-2A
Accessories:
1
Set of safety measurement cables, 4mm, 31 pcs
Set of safety measurement cables, 4mm, 31 pcs SO5148-1L
20
Safety connecting plug 4mm with tap (2x), black, 1000V/32A CAT II
Safety connecting plug 4mm with tap (2x), black, 1000V/32A CAT II SO5126-3R
2
Safety connecting plug 4mm with tap (2x), blue, 1000V/32A CAT II
Safety connecting plug 4mm with tap (2x), blue, 1000V/32A CAT II SO5126-3V
2
Safety connecting plug 4mm with tap (2x), gr/ye, 1000V/32A CAT II
Safety connecting plug 4mm with tap (2x), gr/ye, 1000V/32A CAT II SO5126-3W
1
Mobile aluminum experiment stand, 3 levels, power strip with 6 sockets, 49"x28"x79" WxDxH (1250x700x1995mm)
Mobile aluminum experiment stand, 3 levels, power strip with 6 sockets, 49"x28"x79" WxDxH (1250x700x1995mm) ST7200-4C
1
Protected power distribution for working stations
Protected power distribution for working stations ST8008-8N
1
Monitor holder for flat screen monitor of weight up to 15kg / 33lbs
Monitor holder for flat screen monitor of weight up to 15kg / 33lbs ST8010-4T
1
Keyboard adapter for flat screen monitor holders
Keyboard adapter for flat screen monitor holders ST8010-4G
1
Protection cover for three-level experiment trolleys
Protection cover for three-level experiment trolleys ST8010-9Y
