Item No.: SH5002-7J

Manual, EloTrain: Basic electronic circuits

High-quality, bound, colour teachers’ manual with rigid spine, including solutions. CD-ROM with additional students’ manual, including exercises and worksheets.

Details:

  • Theoretical background

  • Colour CAD drawings for experiment set-ups and circuits

  • Exercises and worksheets

  • Printed on high-quality 100-g/m² colour copy paper, book cover on 210-g/m² glossy paper



Training contents:

  • Basic amplifier circuits using bipolar transistors

  • Basic amplifier circuits using field effect transistors (FETs)

  • Two-stage AC amplifier

  • Darlington pair amplifier

  • Coupled emitter amplifiers

  • Phase reversing stages

  • Differential amplifiers

  • Two-stage DC amplifier with complementary transistors

  • Push-pull amplifiers

  • Positive and negative feedback

  • Square-wave generators

  • Threshold switches (Schmitt triggers)

  • Astable multivibrators

  • Monostable multivibrators

  • Bistable multivibrators (flip-flops)

  • Saw tooth generators (pulse generators)

  • Sine-wave generators with RC and LC elements

  • Amplitude modulators and demodulators

  • Frequency modulators

  • Single-phase and three-phase rectifier circuits

  • Voltage multipliers

  • Stabilising circuits

  • Voltage and current regulators (linear)

  • Switched-mode voltage regulators

  • DC converters

  • Pulse generation using unijunction transistors

  • Phase control using thyristors

  • Phase control using triacs

  • Full-wave control with zero-voltage switch

  • DC voltage switch using thyristors

  • Using op amps as inverting amplifiers

  • Using op amps as non-inverting amplifiers

  • Using op amps as differential amplifiers

  • Dynamic response of operational amplifiers (op amps)
