EPE 41-1 Frequency converter drives with three-phase asynchronous motor 1kW

EPE 41-1 Frequency converter drives with three-phase asynchronous motor 1kW

Training objectives:

  • Investigation of converters for voltage and frequency control
  • Investigation of converters for space vector modulation
  • Analysis of voltage and frequency relationships
  • Primary resistor compensation
  • Investigation of converter drive
  • Computer-based parameter setting and animation
