PEC 11 Fluid power trainer Basic Electric and Electro-Pneumatics

PEC 11 Fluid power trainer Basic Electric and Electro-Pneumatics

Project exercises on electropneumatics :

  • Master control of single-acting cylinders, valve with
  • spring return
  • Master control of double-acting cylinders, valve with
  • spring return
  • Hold element control, double-acting cylinder, pulse valve, direct
  • Operated
  • Hold element control, double-acting cylinder, pulse valve, relay
  • Basic circuit with AND links
  • Basic circuit with OR links
  • Basic circuits with electric self-holding circuits
  • Distance dependent control, double-acting cylinder, 1 elect.
  • position switch
  • Distance dependent control of double-acting cylinders, pulse
  • valve, cylinder switch
  • Distance dependent control of double-acting cylinders, valve
  • with spring return, cylinder switch
  • Stop controls, double-acting cylinder, 5/3 directional valve in
  • locked central position
  • Time-dependent control, double-acting cylinder, pick-up delay
  • Time-dependent control, double-acting cylinder, release
  • time delay
  • Pressure-dependent control, double-acting cylinder
  • Two-hand safety control, electric
  • Sequence control, 2 double-acting cylinders, pulse valves
  • Sequence control, 2 double-acting cylinders, pulse valves, signal
  • Overlapping
  • Sequence control, 2 double-acting cylinders, spring-returned
  • valves, step chain
  • Sequence control, 3 double-acting cylinders, pulse valves,
  • step chain
  • Sequence control, 3 double-acting cylinders, spring-returned
  • valves, step chain
  • Grafcet
